Classes
enum	OptType

Public Member Functions
	CSG ()

CSG	addDatumReference (Transform t)

CSG	prepForManufacturing ()

Color	getColor ()

CSG	setColor (Color color)

CSG	setTemporaryColor (Color color)

CSG	setManipulator (Affine manipulator)

MeshView	getMesh ()

MeshView	newMesh ()

CSG	toZMin (CSG target)

CSG	toZMax (CSG target)

CSG	toXMin (CSG target)

CSG	toXMax (CSG target)

CSG	toYMin (CSG target)

CSG	toYMax (CSG target)

CSG	toZMin ()

CSG	toZMax ()

CSG	toXMin ()

CSG	toXMax ()

CSG	toYMin ()

CSG	toYMax ()

CSG	move (Number x, Number y, Number z)

CSG	move (Vertex v)

CSG	move (Vector3d v)

CSG	move (Number[] posVector)

CSG	movey (Number howFarToMove)

CSG	movez (Number howFarToMove)

CSG	movex (Number howFarToMove)

CSG	moveToCenterX ()

CSG	moveToCenterY ()

CSG	moveToCenterZ ()

CSG	moveToCenter ()

ArrayList< CSG >	move (ArrayList< Transform > p)

CSG	mirrory ()

CSG	mirrorz ()

CSG	mirrorx ()

CSG	rot (Number x, Number y, Number z)

CSG	rot (Number[] posVector)

CSG	rotz (Number degreesToRotate)

CSG	roty (Number degreesToRotate)

CSG	rotx (Number degreesToRotate)

CSG	scalez (Number scaleValue)

CSG	scaley (Number scaleValue)

CSG	scalex (Number scaleValue)

CSG	scale (Number scaleValue)

CSG	clone ()

List< Polygon >	getPolygons ()

CSG	optimization (OptType type)

CSG	union (CSG csg)

CSG	dumbUnion (CSG csg)

CSG	union (List< CSG > csgs)

CSG	union (CSG... csgs)

CSG	hull ()

CSG	hull (List< CSG > csgs)

CSG	hull (CSG... csgs)

CSG	difference (List< CSG > csgs)

CSG	difference (CSG... csgs)

CSG	difference (CSG csg)

CSG	intersect (CSG csg)

CSG	intersect (List< CSG > csgs)

CSG	intersect (CSG... csgs)

String	toStlString ()

StringBuilder	toStlString (StringBuilder sb)

CSG	triangulate ()

CSG	triangulate (boolean fix)

CSG	color (Color c)

StringBuilder	toObjString (StringBuilder sb)

String	toObjString ()

CSG	weighted (WeightFunction f)

CSG	transformed (Transform transform)

MeshContainer	toJavaFXMesh (CadInteractionEvent interact)

MeshContainer	toJavaFXMeshSimple (CadInteractionEvent interact)

Bounds	getBounds ()

Vector3d	getCenter ()

double	getCenterX ()

double	getCenterY ()

double	getCenterZ ()

double	getMaxX ()

double	getMaxY ()

double	getMaxZ ()

double	getMinX ()

double	getMinY ()

double	getMinZ ()

double	getTotalX ()

double	getTotalY ()

double	getTotalZ ()

void	setOptType (OptType optType)

void	setPolygons (List< Polygon > polygons)

ArrayList< CSG >	minovsky (CSG travelingShape)

ArrayList< CSG >	mink (CSG travelingShape)

ArrayList< CSG >	minkowskiHullShape (CSG travelingShape)

ArrayList< CSG >	minkowski (CSG travelingShape)

CSG	minkowskiDifference (CSG itemToDifference, CSG minkowskiObject)

CSG	minkowskiDifference (CSG itemToDifference, double tolerance)

CSG	toolOffset (Number sn)

CSG	makeKeepaway (Number sn)

Affine	getManipulator ()

CSG	addCreationEventStackTraceList (ArrayList< Exception > incoming)

CSG	historySync (CSG dyingCSG)

CSG	addCreationEventStringList (ArrayList< String > incoming)

CSG	addCreationEventString (String thisline)

ArrayList< String >	getCreationEventStackTraceList ()

CSG	prepMfg ()

PrepForManufacturing	getManufacturing ()

PrepForManufacturing	getMfg ()

CSG	setMfg (PrepForManufacturing manufactuing)

CSG	setManufacturing (PrepForManufacturing manufactuing)

PrepForManufacturing	getManufactuing ()

CSG	setManufactuing (PrepForManufacturing manufactuing)

CSG	setParameter (Parameter w, IParametric function)

CSG	setParameter (Parameter w)

CSG	setParameter (String key, double defaultValue, double upperBound, double lowerBound, IParametric function)

CSG	setParameterIfNull (String key)

Set< String >	getParameters ()

CSG	setParameterNewValue (String key, double newValue)

CSG	setRegenerate (IRegenerate function)

CSG	regenerate ()

HashMap< String, IParametric >	getMapOfparametrics ()

boolean	isMarkedForRegeneration ()

void	markForRegeneration ()

boolean	touching (CSG incoming)

CSG	getBoundingBox ()

String	getName ()

CSG	setName (String name)

String	toString ()

ArrayList< Transform >	getSlicePlanes ()

void	addSlicePlane (Transform slicePlane)

ArrayList< String >	getExportFormats ()

void	clearExportFormats ()

void	addExportFormat (String exportFormat)

ArrayList< Transform >	getDatumReferences ()

PropertyStorage	getStorage ()

void	setStorage (PropertyStorage storage)

ArrayList< CSG >	addTabs (Vector3d edgeDirection, CSG fastener) throws Exception

ArrayList< CSG >	addTabs (Vector3d edgeDirection, LengthParameter fastenerHoleDiameter) throws Exception

PropertyStorage	getAssemblyStorage ()

boolean	isWireFrame ()

void	setIsWireFrame (boolean b)

void	setPrintBedNumber (int index)

int	getPrintBedIndex ()

Static Public Member Functions
static ArrayList< CSG >	move (ArrayList< CSG > slice, ArrayList< Transform > p)

static CSG	fromPolygons (List< Polygon > polygons)

static CSG	fromPolygons (Polygon... polygons)

static CSG	fromPolygons (PropertyStorage storage, List< Polygon > polygons)

static CSG	fromPolygons (PropertyStorage storage, Polygon... polygons)

static CSG	unionAll (CSG... csgs)

static CSG	unionAll (List< CSG > csgs)

static CSG	hullAll (CSG... csgs)

static CSG	hullAll (List< CSG > csgs)

static void	setDefaultOptType (OptType optType)

static ICSGProgress	getProgressMoniter ()

static void	setProgressMoniter (ICSGProgress progressMoniter)

static Color	getDefaultColor ()

static void	setDefaultColor (Color defaultcolor)

static int	getNumfacesinoffset ()

static int	getNumFacesInOffset ()

static void	setNumFacesInOffset (int numFacesInOffset)

static boolean	isUseStackTraces ()

static void	setUseStackTraces (boolean useStackTraces)

static CSG	text (String text, double height, double fontSize)

static CSG	text (String text, double height)

static CSG	text (String text, double height, double fontSize, String fontType)

static CSG	textToSize (String text, double x, double y, double z)

Static Public Attributes
static final int	INDEX_OF_PARAMETRIC_DEFAULT = 0

static final int	INDEX_OF_PARAMETRIC_LOWER = 1

static final int	INDEX_OF_PARAMETRIC_UPPER = 2

Private Member Functions
CSG	_unionCSGBoundsOpt (CSG csg)

CSG	_unionPolygonBoundsOpt (CSG csg)

CSG	_unionIntersectOpt (CSG csg)

CSG	_unionNoOpt (CSG csg)

CSG	_differenceCSGBoundsOpt (CSG csg)

CSG	_differencePolygonBoundsOpt (CSG csg)

CSG	_differenceNoOpt (CSG csg)

void	fixDegenerates (ArrayList< Polygon > toAdd, Polygon p)

void	updatePolygons (ArrayList< Polygon > toAdd, ArrayList< Polygon > degenerates, Polygon p)

OptType	getOptType ()

int	getNumFacesForOffsets ()

void	addStackTrace (Exception creationEventStackTrace2)

void	setDatumReferences (ArrayList< Transform > datumReferences)

Transform	addTabsReorientation (Vector3d edgeDirection) throws Exception

Private Attributes
List< Polygon >	polygons

OptType	optType = null

PropertyStorage	str

PropertyStorage	assembly

MeshView	current

Color	color = getDefaultColor()

Affine	manipulator

Bounds	bounds

ArrayList< String >	groovyFileLines = new ArrayList<>()

PrepForManufacturing	manufactuing = null

HashMap< String, IParametric >	mapOfparametrics = null

IRegenerate	regenerate = null

boolean	markForRegeneration = false

String	name = ""

ArrayList< Transform >	slicePlanes = null

ArrayList< String >	exportFormats = null

ArrayList< Transform >	datumReferences = null

boolean	triangulated

Static Private Attributes
static IDebug3dProvider	providerOf3d = null

static int	numFacesInOffset = 15

static OptType	defaultOptType = OptType.CSG_BOUND

static Color	defaultcolor = Color.web("#007956")

static boolean	needsDegeneratesPruned =false

static boolean	useStackTraces = true

static ICSGProgress	progressMoniter

Detailed Description

Constructive Solid Geometry (CSG).

This implementation is a Java port of

https://github.com/evanw/csg.js/ with some additional features like polygon extrude, transformations etc. Thanks to the author for creating the CSG.js library.

Implementation Details

All CSG operations are implemented in terms of two functions, Node#clipTo(eu.mihosoft.vrl.v3d.Node) and Node#invert(), which remove parts of a BSP tree inside another BSP tree and swap solid and empty space, respectively. To find the union of

a

and

b

, we want to remove everything in

a

inside

b

and everything in

b

inside

a

, then combine polygons from

a

and

b

into one solid:

    a.clipTo(b);
    b.clipTo(a);
    a.build(b.allPolygons());

The only tricky part is handling overlapping coplanar polygons in both trees. The code above keeps both copies, but we need to keep them in one tree and remove them in the other tree. To remove them from

b

we can clip the inverse of

b

against

a

. The code for union now looks like this:

    a.clipTo(b);
    b.clipTo(a);
    b.invert();
    b.clipTo(a);
    b.invert();
    a.build(b.allPolygons());

Subtraction and intersection naturally follow from set operations. If union is

A | B

, differenceion is

A - B = ~(~A | B)

and intersection is

A & B =

~(~A | ~B)

where

~

is the complement operator.

Definition at line 109 of file CSG.java.

Constructor & Destructor Documentation

◆ CSG()

eu.mihosoft.vrl.v3d.CSG.CSG ( )

Instantiates a new csg.

Definition at line 163 of file CSG.java.

Member Function Documentation

◆ _differenceCSGBoundsOpt()

CSG eu.mihosoft.vrl.v3d.CSG._differenceCSGBoundsOpt ( CSG csg )

private

_difference csg bounds opt.

Parameters

csg the csg

Returns: the csg

Definition at line 1181 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG._unionIntersectOpt(), eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.optimization(), eu.mihosoft.vrl.v3d.CSG.setName(), and eu.mihosoft.vrl.v3d.Bounds.toCSG().

Here is the call graph for this function:

◆ _differenceNoOpt()

CSG eu.mihosoft.vrl.v3d.CSG._differenceNoOpt ( CSG csg )

private

_difference no opt.

Parameters

csg the csg

Returns: the csg

Definition at line 1231 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.clone(), eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceCSGBoundsOpt(), and eu.mihosoft.vrl.v3d.CSG._differencePolygonBoundsOpt().

Here is the call graph for this function:

◆ _differencePolygonBoundsOpt()

CSG eu.mihosoft.vrl.v3d.CSG._differencePolygonBoundsOpt ( CSG csg )

private

_difference polygon bounds opt.

Parameters

csg the csg

Returns: the csg

Definition at line 1199 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.Bounds.intersects(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Here is the call graph for this function:

◆ _unionCSGBoundsOpt()

CSG eu.mihosoft.vrl.v3d.CSG._unionCSGBoundsOpt ( CSG csg )

private

_union csg bounds opt.

Parameters

csg the csg

Returns: the csg

Definition at line 937 of file CSG.java.

◆ _unionIntersectOpt()

CSG eu.mihosoft.vrl.v3d.CSG._unionIntersectOpt ( CSG csg )

private

Optimizes for intersection. If csgs do not intersect create a new csg that consists of the polygon lists of this csg and the specified csg. In this case no further space partitioning is performed.

Parameters

csg csg

Returns: the union of this csg and the specified csg

Definition at line 990 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.Bounds.intersects(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceCSGBoundsOpt().

Here is the call graph for this function:

◆ _unionNoOpt()

CSG eu.mihosoft.vrl.v3d.CSG._unionNoOpt ( CSG csg )

private

_union no opt.

Parameters

csg the csg

Returns: the csg

Definition at line 1023 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.clone(), eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Referenced by eu.mihosoft.vrl.v3d.CSG._unionPolygonBoundsOpt().

Here is the call graph for this function:

◆ _unionPolygonBoundsOpt()

CSG eu.mihosoft.vrl.v3d.CSG._unionPolygonBoundsOpt ( CSG csg )

private

_union polygon bounds opt.

Parameters

csg the csg

Returns: the csg

Definition at line 949 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG._unionNoOpt(), eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.Bounds.intersects(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Here is the call graph for this function:

◆ addCreationEventStackTraceList()

CSG eu.mihosoft.vrl.v3d.CSG.addCreationEventStackTraceList ( ArrayList< Exception > incoming )

Definition at line 2120 of file CSG.java.

◆ addCreationEventString()

CSG eu.mihosoft.vrl.v3d.CSG.addCreationEventString ( String thisline )

Definition at line 2188 of file CSG.java.

◆ addCreationEventStringList()

CSG eu.mihosoft.vrl.v3d.CSG.addCreationEventStringList ( ArrayList< String > incoming )

Definition at line 2179 of file CSG.java.

◆ addDatumReference()

CSG eu.mihosoft.vrl.v3d.CSG.addDatumReference ( Transform t )

Definition at line 172 of file CSG.java.

◆ addExportFormat()

void eu.mihosoft.vrl.v3d.CSG.addExportFormat ( String exportFormat )

Parameters

exportFormat the exportFormat to add

Definition at line 2420 of file CSG.java.

◆ addSlicePlane()

void eu.mihosoft.vrl.v3d.CSG.addSlicePlane ( Transform slicePlane )

Definition at line 2398 of file CSG.java.

◆ addStackTrace()

void eu.mihosoft.vrl.v3d.CSG.addStackTrace ( Exception creationEventStackTrace2 )

private

Definition at line 2128 of file CSG.java.

◆ addTabs() [1/2]

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.addTabs	(	Vector3d	edgeDirection,
		CSG	fastener
	)		throws Exception

Adds construction tabs to a given CSG object in order to facilitate connection with other boards and returns the CSG with tabs added plus separate fastener objects interspersed between tabs. Assumes board thickness is the thinnest dimension. Assumes board thickness can be arbitrary but uniform height. Assumes the edge having tabs added extends fully between Min and Max in that dimension.

TODO: Find the polygon defined by the XY plane slice that is perhaps 0.5mm into the normalized +Y. Add tabs to THAT polygon's minX/maxX instead of part's global minX/maxX.

Example usage: // Create a temporary copy of the target object, without any tabs CSG boardTemp = board

// Instantiate a bucket to hold fastener CSG objects in ArrayList<CSG> fasteners = []

// Define the direction of the edge to be tabbed using a Vector3d object, in this case the edge facing in the negative Y direction Vector3d edgeDirection = new Vector3d(0, -1, 0);

// Define the diameter of the fastener holes to be added using a LengthParameter object LengthParameter screwDiameter = new LengthParameter("Screw Hole Diameter (mm)", 3, [0, 20])

// Add tabs to the temporary object using the edgeDirection and screwDiameter parameters ArrayList<CSG> returned = boardTemp.addTabs(edgeDirection, screwDiameter);

// Combine the modified temporary object with the original object, to add the new tabs board = boardTemp.union(returned.get(0));

// Add the separate fastener hole objects to the list fasteners = returned.subList(1, returned.size());

Parameters

edgeDirection	a Vector3d object representing the direction of the edge of the board to which tabs and fastener holes will be added
fastener	a CSG object representing a template fastener to be added between the tabs

Returns: an ArrayList of CSG objects representing the original board with added tabs and separate fastener hole objects

Exceptions

Exception if the edgeDirection parameter is not a cartesian unit Vector3d object or uses an unimplemented orientation

Definition at line 2513 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getMaxX(), eu.mihosoft.vrl.v3d.CSG.getMaxY(), eu.mihosoft.vrl.v3d.CSG.getMaxZ(), eu.mihosoft.vrl.v3d.CSG.getMinY(), eu.mihosoft.vrl.v3d.CSG.getTotalX(), eu.mihosoft.vrl.v3d.Transform.inverse(), eu.mihosoft.vrl.v3d.CSG.movex(), eu.mihosoft.vrl.v3d.CSG.movey(), eu.mihosoft.vrl.v3d.CSG.movez(), eu.mihosoft.vrl.v3d.CSG.rotx(), eu.mihosoft.vrl.v3d.Primitive.toCSG(), eu.mihosoft.vrl.v3d.CSG.transformed(), and eu.mihosoft.vrl.v3d.CSG.union().

Here is the call graph for this function:

◆ addTabs() [2/2]

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.addTabs	(	Vector3d	edgeDirection,
		LengthParameter	fastenerHoleDiameter
	)		throws Exception

Definition at line 2625 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getMaxZ(), and eu.mihosoft.vrl.v3d.Primitive.toCSG().

Here is the call graph for this function:

◆ addTabsReorientation()

Transform eu.mihosoft.vrl.v3d.CSG.addTabsReorientation ( Vector3d edgeDirection ) throws Exception

private

Parameters

edgeDirection

Returns

Exceptions

Exception

Definition at line 2582 of file CSG.java.

Here is the call graph for this function:

◆ clearExportFormats()

void eu.mihosoft.vrl.v3d.CSG.clearExportFormats ( )

Definition at line 2412 of file CSG.java.

◆ clone()

CSG eu.mihosoft.vrl.v3d.CSG.clone ( )

Definition at line 675 of file CSG.java.

References eu.mihosoft.vrl.v3d.Polygon.clone(), eu.mihosoft.vrl.v3d.CSG.historySync(), eu.mihosoft.vrl.v3d.CSG.setOptType(), and eu.mihosoft.vrl.v3d.CSG.setPolygons().

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG._unionNoOpt(), eu.mihosoft.vrl.v3d.Extrude.bezier(), eu.mihosoft.vrl.v3d.CSG.dumbUnion(), eu.mihosoft.vrl.v3d.Extrude.hull(), and eu.mihosoft.vrl.v3d.CSG.intersect().

Here is the call graph for this function:

◆ color()

CSG eu.mihosoft.vrl.v3d.CSG.color ( Color c )

Color.

Parameters

c the c

Returns: the csg

Definition at line 1555 of file CSG.java.

◆ difference() [1/3]

CSG eu.mihosoft.vrl.v3d.CSG.difference ( CSG csg )

Return a new CSG solid representing the difference of this csg and the specified csg.

Note: Neither this csg nor the specified csg are weighted.

A.difference(B)

+-------+            +-------+
|       |            |       |
|   A   |            |       |
|    +--+----+   =   |    +--+
+----+--+    |       +----+
     |   B   |
     |       |
     +-------+

Parameters

csg other csg

Returns: difference of this csg and the specified csg

Definition at line 1129 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.CSG.historySync(), and eu.mihosoft.vrl.v3d.CSG.intersect().

Here is the call graph for this function:

◆ difference() [2/3]

CSG eu.mihosoft.vrl.v3d.CSG.difference ( CSG... csgs )

Return a new CSG solid representing the difference of this csg and the specified csgs.

Note: Neither this csg nor the specified csgs are weighted.

A.difference(B)

+-------+            +-------+
|       |            |       |
|   A   |            |       |
|    +--+----+   =   |    +--+
+----+--+    |       +----+
     |   B   |
     |       |
     +-------+

Parameters

csgs	other csgs

Returns: difference of this csg and the specified csgs

Definition at line 1102 of file CSG.java.

◆ difference() [3/3]

CSG eu.mihosoft.vrl.v3d.CSG.difference ( List< CSG > csgs )

Return a new CSG solid representing the difference of this csg and the specified csgs.

Note: Neither this csg nor the specified csgs are weighted.

A.difference(B)

+-------+            +-------+
|       |            |       |
|   A   |            |       |
|    +--+----+   =   |    +--+
+----+--+    |       +----+
     |   B   |
     |       |
     +-------+

Parameters

csgs	other csgs

Returns: difference of this csg and the specified csgs

Definition at line 1061 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.historySync(), eu.mihosoft.vrl.v3d.ICSGProgress.progressUpdate(), and eu.mihosoft.vrl.v3d.CSG.union().

Referenced by eu.mihosoft.vrl.v3d.Fillet.corner(), eu.mihosoft.vrl.v3d.CSG.minkowskiDifference(), eu.mihosoft.vrl.v3d.TextExtrude.TextExtrude(), and eu.mihosoft.vrl.v3d.Fillet.toPolygons().

Here is the call graph for this function:

◆ dumbUnion()

CSG eu.mihosoft.vrl.v3d.CSG.dumbUnion ( CSG csg )

Returns a csg consisting of the polygons of this csg and the specified csg.

The purpose of this method is to allow fast union operations for objects that do not intersect.

WARNING: this method does not apply the csg algorithms. Therefore, please ensure that this csg and the specified csg do not intersect.

Parameters

csg csg

Returns: a csg consisting of the polygons of this csg and the specified csg

Definition at line 763 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.clone(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.CSG.historySync(), and eu.mihosoft.vrl.v3d.CSG.triangulated.

Referenced by eu.mihosoft.vrl.v3d.CSG.text().

Here is the call graph for this function:

◆ fixDegenerates()

void eu.mihosoft.vrl.v3d.CSG.fixDegenerates	(	ArrayList< Polygon >	toAdd,
		Polygon	p
	)

private

Definition at line 1456 of file CSG.java.

References eu.mihosoft.vrl.v3d.Debug3dProvider.addObject(), eu.mihosoft.vrl.v3d.Debug3dProvider.clearScreen(), eu.mihosoft.vrl.v3d.ext.org.poly2tri.PolygonUtil.concaveToConvex(), eu.mihosoft.vrl.v3d.Polygon.getDegeneratePoints(), and eu.mihosoft.vrl.v3d.Polygon.getLongEdge().

Here is the call graph for this function:

◆ fromPolygons() [1/4]

static CSG eu.mihosoft.vrl.v3d.CSG.fromPolygons ( List< Polygon > polygons )

static

Constructs a CSG from a list of Polygon instances.

Parameters

polygons polygons

Returns: a CSG instance

Definition at line 621 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.setPolygons().

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG._differencePolygonBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._unionIntersectOpt(), eu.mihosoft.vrl.v3d.CSG._unionNoOpt(), eu.mihosoft.vrl.v3d.CSG._unionPolygonBoundsOpt(), eu.mihosoft.vrl.v3d.STL.file(), eu.mihosoft.vrl.v3d.ext.quickhull3d.HullUtil.hull(), eu.mihosoft.vrl.v3d.CSG.intersect(), eu.mihosoft.vrl.v3d.Extrude.polygons(), eu.mihosoft.vrl.v3d.Primitive.toCSG(), and eu.mihosoft.vrl.v3d.CSG.transformed().

Here is the call graph for this function:

◆ fromPolygons() [2/4]

static CSG eu.mihosoft.vrl.v3d.CSG.fromPolygons ( Polygon... polygons )

static

Constructs a CSG from the specified Polygon instances.

Parameters

polygons polygons

Returns: a CSG instance

Definition at line 634 of file CSG.java.

◆ fromPolygons() [3/4]

static CSG eu.mihosoft.vrl.v3d.CSG.fromPolygons	(	PropertyStorage	storage,
		List< Polygon >	polygons
	)

static

Constructs a CSG from a list of Polygon instances.

Parameters

storage	shared storage
polygons	polygons

Returns: a CSG instance

Definition at line 645 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.setPolygons(), and eu.mihosoft.vrl.v3d.CSG.setStorage().

Here is the call graph for this function:

◆ fromPolygons() [4/4]

static CSG eu.mihosoft.vrl.v3d.CSG.fromPolygons	(	PropertyStorage	storage,
		Polygon...	polygons
	)

static

Constructs a CSG from the specified Polygon instances.

Parameters

storage	shared storage
polygons	polygons

Returns: a CSG instance

Definition at line 665 of file CSG.java.

◆ getAssemblyStorage()

PropertyStorage eu.mihosoft.vrl.v3d.CSG.getAssemblyStorage ( )

Definition at line 2660 of file CSG.java.

◆ getBoundingBox()

CSG eu.mihosoft.vrl.v3d.CSG.getBoundingBox ( )

Get Bounding box

Returns: A CSG that completely encapsulates the base CSG, centered around it

Definition at line 2372 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.movex(), eu.mihosoft.vrl.v3d.CSG.movey(), eu.mihosoft.vrl.v3d.CSG.movez(), eu.mihosoft.vrl.v3d.Primitive.toCSG(), eu.mihosoft.vrl.v3d.CSG.toXMax(), eu.mihosoft.vrl.v3d.CSG.toYMax(), and eu.mihosoft.vrl.v3d.CSG.toZMax().

Here is the call graph for this function:

◆ getBounds()

Bounds eu.mihosoft.vrl.v3d.CSG.getBounds ( )

Returns the bounds of this csg. SIDE EFFECT bounds is created and simply returned if existing

Returns: bouds of this csg

Definition at line 1738 of file CSG.java.

References eu.mihosoft.vrl.v3d.Vertex.pos, eu.mihosoft.vrl.v3d.Vector3d.x(), eu.mihosoft.vrl.v3d.Vector3d.y(), eu.mihosoft.vrl.v3d.Vector3d.z(), and eu.mihosoft.vrl.v3d.Vector3d.ZERO.

Here is the call graph for this function:

◆ getCenter()

Vector3d eu.mihosoft.vrl.v3d.CSG.getCenter ( )

Definition at line 1788 of file CSG.java.

◆ getCenterX()

double eu.mihosoft.vrl.v3d.CSG.getCenterX ( )

Helper function wrapping bounding box values

Returns: CenterX

Definition at line 1797 of file CSG.java.

◆ getCenterY()

double eu.mihosoft.vrl.v3d.CSG.getCenterY ( )

Helper function wrapping bounding box values

Returns: CenterY

Definition at line 1806 of file CSG.java.

◆ getCenterZ()

double eu.mihosoft.vrl.v3d.CSG.getCenterZ ( )

Helper function wrapping bounding box values

Returns: CenterZ

Definition at line 1815 of file CSG.java.

◆ getColor()

Color eu.mihosoft.vrl.v3d.CSG.getColor ( )

Gets the color.

Returns: the color

Definition at line 198 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.historySync().

◆ getCreationEventStackTraceList()

ArrayList<String> eu.mihosoft.vrl.v3d.CSG.getCreationEventStackTraceList ( )

Definition at line 2205 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.historySync().

◆ getDatumReferences()

ArrayList<Transform> eu.mihosoft.vrl.v3d.CSG.getDatumReferences ( )

Definition at line 2451 of file CSG.java.

◆ getDefaultColor()

static Color eu.mihosoft.vrl.v3d.CSG.getDefaultColor ( )

static

Definition at line 2359 of file CSG.java.

◆ getExportFormats()

ArrayList<String> eu.mihosoft.vrl.v3d.CSG.getExportFormats ( )

Returns: the exportFormats

Definition at line 2408 of file CSG.java.

◆ getManipulator()

Affine eu.mihosoft.vrl.v3d.CSG.getManipulator ( )

Definition at line 2114 of file CSG.java.

◆ getManufactuing()

PrepForManufacturing eu.mihosoft.vrl.v3d.CSG.getManufactuing ( )

Definition at line 2231 of file CSG.java.

◆ getManufacturing()

PrepForManufacturing eu.mihosoft.vrl.v3d.CSG.getManufacturing ( )

Definition at line 2213 of file CSG.java.

◆ getMapOfparametrics()

HashMap<String, IParametric> eu.mihosoft.vrl.v3d.CSG.getMapOfparametrics ( )

Definition at line 2312 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.historySync().

◆ getMaxX()

double eu.mihosoft.vrl.v3d.CSG.getMaxX ( )

Helper function wrapping bounding box values

Returns: MaxX

Definition at line 1824 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.addTabsReorientation(), and eu.mihosoft.vrl.v3d.CSG.touching().

◆ getMaxY()

double eu.mihosoft.vrl.v3d.CSG.getMaxY ( )

Helper function wrapping bounding box values

Returns: MaxY

Definition at line 1833 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), and eu.mihosoft.vrl.v3d.CSG.touching().

◆ getMaxZ()

double eu.mihosoft.vrl.v3d.CSG.getMaxZ ( )

Helper function wrapping bounding box values

Returns: MaxZ

Definition at line 1842 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), and eu.mihosoft.vrl.v3d.CSG.touching().

◆ getMesh()

MeshView eu.mihosoft.vrl.v3d.CSG.getMesh ( )

Gets the mesh.

Returns: the mesh

Definition at line 252 of file CSG.java.

◆ getMfg()

PrepForManufacturing eu.mihosoft.vrl.v3d.CSG.getMfg ( )

Definition at line 2217 of file CSG.java.

◆ getMinX()

double eu.mihosoft.vrl.v3d.CSG.getMinX ( )

Helper function wrapping bounding box values

Returns: MinX

Definition at line 1851 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabsReorientation(), and eu.mihosoft.vrl.v3d.CSG.touching().

◆ getMinY()

double eu.mihosoft.vrl.v3d.CSG.getMinY ( )

Helper function wrapping bounding box values

Returns: MinY

Definition at line 1860 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.addTabsReorientation(), and eu.mihosoft.vrl.v3d.CSG.touching().

◆ getMinZ()

double eu.mihosoft.vrl.v3d.CSG.getMinZ ( )

Helper function wrapping bounding box values

Returns: tMinZ

Definition at line 1869 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabsReorientation(), and eu.mihosoft.vrl.v3d.CSG.touching().

◆ getName()

String eu.mihosoft.vrl.v3d.CSG.getName ( )

Definition at line 2378 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceCSGBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG._differencePolygonBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._unionIntersectOpt(), eu.mihosoft.vrl.v3d.CSG._unionNoOpt(), eu.mihosoft.vrl.v3d.CSG._unionPolygonBoundsOpt(), eu.mihosoft.vrl.v3d.CSG.historySync(), and eu.mihosoft.vrl.v3d.CSG.intersect().

◆ getNumFacesForOffsets()

int eu.mihosoft.vrl.v3d.CSG.getNumFacesForOffsets ( )

private

Definition at line 2086 of file CSG.java.

◆ getNumfacesinoffset()

static int eu.mihosoft.vrl.v3d.CSG.getNumfacesinoffset ( )

static

Definition at line 2431 of file CSG.java.

◆ getNumFacesInOffset()

static int eu.mihosoft.vrl.v3d.CSG.getNumFacesInOffset ( )

static

Definition at line 2435 of file CSG.java.

◆ getOptType()

OptType eu.mihosoft.vrl.v3d.CSG.getOptType ( )

private

Gets the opt type.

Returns: the optType

Definition at line 1905 of file CSG.java.

◆ getParameters()

Set<String> eu.mihosoft.vrl.v3d.CSG.getParameters ( )

Definition at line 2284 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.historySync().

◆ getPolygons()

List<Polygon> eu.mihosoft.vrl.v3d.CSG.getPolygons ( )

Gets the polygons.

Returns: the polygons of this CSG

Definition at line 698 of file CSG.java.

◆ getPrintBedIndex()

int eu.mihosoft.vrl.v3d.CSG.getPrintBedIndex ( )

Definition at line 2680 of file CSG.java.

◆ getProgressMoniter()

static ICSGProgress eu.mihosoft.vrl.v3d.CSG.getProgressMoniter ( )

static

Definition at line 2351 of file CSG.java.

◆ getSlicePlanes()

ArrayList<Transform> eu.mihosoft.vrl.v3d.CSG.getSlicePlanes ( )

Definition at line 2394 of file CSG.java.

◆ getStorage()

PropertyStorage eu.mihosoft.vrl.v3d.CSG.getStorage ( )

Definition at line 2459 of file CSG.java.

◆ getTotalX()

double eu.mihosoft.vrl.v3d.CSG.getTotalX ( )

Helper function wrapping bounding box values

Returns: MinX

Definition at line 1878 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.addTabsReorientation(), and eu.mihosoft.vrl.v3d.CSG.textToSize().

◆ getTotalY()

double eu.mihosoft.vrl.v3d.CSG.getTotalY ( )

Helper function wrapping bounding box values

Returns: MinY

Definition at line 1887 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.textToSize().

◆ getTotalZ()

double eu.mihosoft.vrl.v3d.CSG.getTotalZ ( )

Helper function wrapping bounding box values

Returns: tMinZ

Definition at line 1896 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabsReorientation().

◆ historySync()

CSG eu.mihosoft.vrl.v3d.CSG.historySync ( CSG dyingCSG )

Definition at line 2156 of file CSG.java.

References eu.mihosoft.vrl.v3d.parametrics.CSGDatabase.get(), eu.mihosoft.vrl.v3d.CSG.getColor(), eu.mihosoft.vrl.v3d.CSG.getCreationEventStackTraceList(), eu.mihosoft.vrl.v3d.CSG.getMapOfparametrics(), eu.mihosoft.vrl.v3d.CSG.getName(), and eu.mihosoft.vrl.v3d.CSG.getParameters().

Referenced by eu.mihosoft.vrl.v3d.CSG.clone(), eu.mihosoft.vrl.v3d.CSG.difference(), eu.mihosoft.vrl.v3d.CSG.dumbUnion(), eu.mihosoft.vrl.v3d.CSG.hull(), eu.mihosoft.vrl.v3d.CSG.intersect(), eu.mihosoft.vrl.v3d.CSG.makeKeepaway(), eu.mihosoft.vrl.v3d.CSG.transformed(), and eu.mihosoft.vrl.v3d.CSG.union().

Here is the call graph for this function:

◆ hull() [1/3]

CSG eu.mihosoft.vrl.v3d.CSG.hull ( )

Returns the convex hull of this csg.

Returns: the convex hull of this csg

Definition at line 866 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.historySync(), and eu.mihosoft.vrl.v3d.ext.quickhull3d.HullUtil.hull().

Referenced by eu.mihosoft.vrl.v3d.CSG.hull(), eu.mihosoft.vrl.v3d.ChamferedCube.toPolygons(), eu.mihosoft.vrl.v3d.ChamferedCylinder.toPolygons(), and eu.mihosoft.vrl.v3d.RoundedCube.toPolygons().

Here is the call graph for this function:

◆ hull() [2/3]

CSG eu.mihosoft.vrl.v3d.CSG.hull ( CSG... csgs )

Returns the convex hull of this csg and the union of the specified csgs.

Parameters

csgs csgs

Returns: the convex hull of this csg and the specified csgs

Definition at line 926 of file CSG.java.

◆ hull() [3/3]

CSG eu.mihosoft.vrl.v3d.CSG.hull ( List< CSG > csgs )

Returns the convex hull of this csg and the union of the specified csgs.

Parameters

csgs csgs

Returns: the convex hull of this csg and the specified csgs

Definition at line 895 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.CSG.historySync(), eu.mihosoft.vrl.v3d.CSG.hull(), eu.mihosoft.vrl.v3d.CSG.optType, and eu.mihosoft.vrl.v3d.CSG.setPolygons().

Here is the call graph for this function:

◆ hullAll() [1/2]

static CSG eu.mihosoft.vrl.v3d.CSG.hullAll ( CSG... csgs )

static

Definition at line 880 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.Extrude.revolve().

◆ hullAll() [2/2]

static CSG eu.mihosoft.vrl.v3d.CSG.hullAll ( List< CSG > csgs )

static

Definition at line 884 of file CSG.java.

References eu.mihosoft.vrl.v3d.ext.quickhull3d.HullUtil.hull().

Here is the call graph for this function:

◆ intersect() [1/3]

CSG eu.mihosoft.vrl.v3d.CSG.intersect ( CSG csg )

Return a new CSG solid representing the intersection of this csg and the specified csg.

Note: Neither this csg nor the specified csg are weighted.

    A.intersect(B)

    +-------+
    |       |
    |   A   |
    |    +--+----+   =   +--+
    +----+--+    |       +--+
         |   B   |
         |       |
         +-------+
}

Parameters

csg other csg

Returns: intersection of this csg and the specified csg

Definition at line 1275 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.clone(), eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.getName(), eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.CSG.historySync(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Referenced by eu.mihosoft.vrl.v3d.CSG.difference(), and eu.mihosoft.vrl.v3d.CSG.toolOffset().

Here is the call graph for this function:

◆ intersect() [2/3]

CSG eu.mihosoft.vrl.v3d.CSG.intersect ( CSG... csgs )

Return a new CSG solid representing the intersection of this csg and the specified csgs.

Note: Neither this csg nor the specified csgs are weighted.

    A.intersect(B)

    +-------+
    |       |
    |   A   |
    |    +--+----+   =   +--+
    +----+--+    |       +--+
         |   B   |
         |       |
         +-------+
}

Parameters

csgs	other csgs

Returns: intersection of this csg and the specified csgs

Definition at line 1360 of file CSG.java.

◆ intersect() [3/3]

CSG eu.mihosoft.vrl.v3d.CSG.intersect ( List< CSG > csgs )

Return a new CSG solid representing the intersection of this csg and the specified csgs.

Note: Neither this csg nor the specified csgs are weighted.

    A.intersect(B)

    +-------+
    |       |
    |   A   |
    |    +--+----+   =   +--+
    +----+--+    |       +--+
         |   B   |
         |       |
         +-------+
}

Parameters

csgs	other csgs

Returns: intersection of this csg and the specified csgs

Definition at line 1318 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.historySync(), eu.mihosoft.vrl.v3d.ICSGProgress.progressUpdate(), and eu.mihosoft.vrl.v3d.CSG.union().

Here is the call graph for this function:

◆ isMarkedForRegeneration()

boolean eu.mihosoft.vrl.v3d.CSG.isMarkedForRegeneration ( )

Definition at line 2319 of file CSG.java.

◆ isUseStackTraces()

static boolean eu.mihosoft.vrl.v3d.CSG.isUseStackTraces ( )

static

Definition at line 2443 of file CSG.java.

◆ isWireFrame()

boolean eu.mihosoft.vrl.v3d.CSG.isWireFrame ( )

Definition at line 2666 of file CSG.java.

◆ makeKeepaway()

CSG eu.mihosoft.vrl.v3d.CSG.makeKeepaway ( Number sn )

Definition at line 2090 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.historySync(), and eu.mihosoft.vrl.v3d.CSG.transformed().

Here is the call graph for this function:

◆ markForRegeneration()

void eu.mihosoft.vrl.v3d.CSG.markForRegeneration ( )

Definition at line 2323 of file CSG.java.

◆ mink()

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.mink ( CSG travelingShape )

Shortened name In case you forget the name of minkowski

Parameters

travelingShape

Returns

Definition at line 1971 of file CSG.java.

◆ minkowski()

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.minkowski ( CSG travelingShape )

This is a simplified version of a minkowski transform using convex hull and the internal list of convex polygons The shape is placed at the vertex of each point on a polygon, and the result is convex hulled together. This collection is returned. To make a normal insets, difference this collection To make an outset by the normals, union this collection with this object.

Parameters

travelingShape a shape to sweep around

Returns

Definition at line 2012 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getPolygons().

Here is the call graph for this function:

◆ minkowskiDifference() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.minkowskiDifference	(	CSG	itemToDifference,
		CSG	minkowskiObject
	)

minkowskiDifference performs an efficient difference of the minkowski transform of the intersection of an object. if you have 2 objects and need them to fit with a specific tolerance as described as the distance from he normal of the surface, then this function will effectinatly compute that value.

Parameters

itemToDifference	the object that needs to fit
minkowskiObject	the object to represent the offset

Returns

Definition at line 2034 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.difference(), eu.mihosoft.vrl.v3d.CSG.minkowskiHullShape(), and eu.mihosoft.vrl.v3d.ICSGProgress.progressUpdate().

Here is the call graph for this function:

◆ minkowskiDifference() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.minkowskiDifference	(	CSG	itemToDifference,
		double	tolerance
	)

minkowskiDifference performs an efficient difference of the minkowski transform of the intersection of an object. if you have 2 objects and need them to fit with a specific tolerance as described as the distance from the normal of the surface, then this function will effectinatly compute that value.

Parameters

itemToDifference	the object that needs to fit
tolerance	the tolerance distance

Returns

Definition at line 2057 of file CSG.java.

◆ minkowskiHullShape()

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.minkowskiHullShape ( CSG travelingShape )

This is a simplified version of a minkowski transform using convex hull and the internal list of convex polygons The shape is placed at the vertex of each point on a polygon, and the result is convex hulled together. This collection is returned. To make a normal insets, difference this collection To make an outset by the normals, union this collection with this object.

Parameters

travelingShape a shape to sweep around

Returns

Definition at line 1985 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getPolygons(), eu.mihosoft.vrl.v3d.ext.quickhull3d.HullUtil.hull(), eu.mihosoft.vrl.v3d.CSG.move(), and eu.mihosoft.vrl.v3d.Vertex.pos.

Referenced by eu.mihosoft.vrl.v3d.CSG.minkowskiDifference().

Here is the call graph for this function:

◆ minovsky()

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.minovsky ( CSG travelingShape )

Hail Zeon! In case you forget the name of minkowski and are a Gundam fan

Parameters

travelingShape

Returns

Definition at line 1960 of file CSG.java.

◆ mirrorx()

CSG eu.mihosoft.vrl.v3d.CSG.mirrorx ( )

mirror about x axis.

Returns: the csg

Definition at line 531 of file CSG.java.

◆ mirrory()

CSG eu.mihosoft.vrl.v3d.CSG.mirrory ( )

mirror about y axis.

Returns: the csg

Definition at line 513 of file CSG.java.

◆ mirrorz()

CSG eu.mihosoft.vrl.v3d.CSG.mirrorz ( )

mirror about z axis.

Returns: the csg

Definition at line 522 of file CSG.java.

◆ move() [1/6]

static ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.move	(	ArrayList< CSG >	slice,
		ArrayList< Transform >	p
	)

static

Definition at line 497 of file CSG.java.

◆ move() [2/6]

ArrayList<CSG> eu.mihosoft.vrl.v3d.CSG.move ( ArrayList< Transform > p )

Definition at line 489 of file CSG.java.

◆ move() [3/6]

CSG eu.mihosoft.vrl.v3d.CSG.move	(	Number	x,
		Number	y,
		Number	z
	)

Definition at line 406 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.minkowskiHullShape(), eu.mihosoft.vrl.v3d.Extrude.move(), and eu.mihosoft.vrl.v3d.Fillet.outerFillet().

◆ move() [4/6]

CSG eu.mihosoft.vrl.v3d.CSG.move ( Number[] posVector )

Definition at line 418 of file CSG.java.

◆ move() [5/6]

CSG eu.mihosoft.vrl.v3d.CSG.move ( Vector3d v )

Definition at line 414 of file CSG.java.

References eu.mihosoft.vrl.v3d.Vector3d.x(), eu.mihosoft.vrl.v3d.Vector3d.y(), and eu.mihosoft.vrl.v3d.Vector3d.z().

Here is the call graph for this function:

◆ move() [6/6]

CSG eu.mihosoft.vrl.v3d.CSG.move ( Vertex v )

Definition at line 410 of file CSG.java.

References eu.mihosoft.vrl.v3d.Vertex.getX(), eu.mihosoft.vrl.v3d.Vertex.getY(), and eu.mihosoft.vrl.v3d.Vertex.getZ().

Here is the call graph for this function:

◆ moveToCenter()

CSG eu.mihosoft.vrl.v3d.CSG.moveToCenter ( )

Helper function moving CSG to center X, Y, Z moveToCenter. Moves in x, y, z

Returns: the csg

Definition at line 485 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.movey(), and eu.mihosoft.vrl.v3d.CSG.movez().

Here is the call graph for this function:

◆ moveToCenterX()

CSG eu.mihosoft.vrl.v3d.CSG.moveToCenterX ( )

Helper function moving CSG to center X moveToCenterX.

Returns: the csg

Definition at line 458 of file CSG.java.

◆ moveToCenterY()

CSG eu.mihosoft.vrl.v3d.CSG.moveToCenterY ( )

Helper function moving CSG to center Y moveToCenterY.

Returns: the csg

Definition at line 467 of file CSG.java.

◆ moveToCenterZ()

CSG eu.mihosoft.vrl.v3d.CSG.moveToCenterZ ( )

Helper function moving CSG to center Z moveToCenterZ.

Returns: the csg

Definition at line 476 of file CSG.java.

◆ movex()

CSG eu.mihosoft.vrl.v3d.CSG.movex ( Number howFarToMove )

Movex.

Parameters

howFarToMove the how far to move

Returns: the csg

Definition at line 449 of file CSG.java.

References eu.mihosoft.vrl.v3d.Transform.translateX(), and eu.mihosoft.vrl.v3d.Transform.unity().

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), and eu.mihosoft.vrl.v3d.CSG.getBoundingBox().

Here is the call graph for this function:

◆ movey()

CSG eu.mihosoft.vrl.v3d.CSG.movey ( Number howFarToMove )

Movey.

Parameters

howFarToMove the how far to move

Returns: the csg

Definition at line 429 of file CSG.java.

References eu.mihosoft.vrl.v3d.Transform.translateY(), and eu.mihosoft.vrl.v3d.Transform.unity().

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.getBoundingBox(), eu.mihosoft.vrl.v3d.CSG.moveToCenter(), eu.mihosoft.vrl.v3d.Extrude.revolve(), and eu.mihosoft.vrl.v3d.Fillet.toPolygons().

Here is the call graph for this function:

◆ movez()

CSG eu.mihosoft.vrl.v3d.CSG.movez ( Number howFarToMove )

Movez.

Parameters

howFarToMove the how far to move

Returns: the csg

Definition at line 439 of file CSG.java.

References eu.mihosoft.vrl.v3d.Transform.translateZ(), and eu.mihosoft.vrl.v3d.Transform.unity().

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.getBoundingBox(), eu.mihosoft.vrl.v3d.CSG.moveToCenter(), eu.mihosoft.vrl.v3d.ChamferedCylinder.toPolygons(), and eu.mihosoft.vrl.v3d.RoundedCylinder.toPolygons().

Here is the call graph for this function:

◆ newMesh()

MeshView eu.mihosoft.vrl.v3d.CSG.newMesh ( )

Gets the mesh.

Returns: the mesh

Definition at line 264 of file CSG.java.

References eu.mihosoft.vrl.v3d.MeshContainer.getAsMeshViews().

Here is the call graph for this function:

◆ optimization()

CSG eu.mihosoft.vrl.v3d.CSG.optimization ( OptType type )

Defines the CSg optimization type.

Parameters

type	optimization type

Returns: this CSG

Definition at line 708 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceCSGBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG._differencePolygonBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._unionIntersectOpt(), eu.mihosoft.vrl.v3d.CSG._unionNoOpt(), eu.mihosoft.vrl.v3d.CSG._unionPolygonBoundsOpt(), eu.mihosoft.vrl.v3d.CSG.intersect(), and eu.mihosoft.vrl.v3d.CSG.transformed().

◆ prepForManufacturing()

CSG eu.mihosoft.vrl.v3d.CSG.prepForManufacturing ( )

Definition at line 179 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.exportFormats, eu.mihosoft.vrl.v3d.CSG.mapOfparametrics, eu.mihosoft.vrl.v3d.CSG.setColor(), eu.mihosoft.vrl.v3d.CSG.setName(), and eu.mihosoft.vrl.v3d.CSG.slicePlanes.

Here is the call graph for this function:

◆ prepMfg()

CSG eu.mihosoft.vrl.v3d.CSG.prepMfg ( )

Definition at line 2209 of file CSG.java.

◆ regenerate()

CSG eu.mihosoft.vrl.v3d.CSG.regenerate ( )

Definition at line 2302 of file CSG.java.

References eu.mihosoft.vrl.v3d.parametrics.IRegenerate.regenerate(), eu.mihosoft.vrl.v3d.CSG.setColor(), and eu.mihosoft.vrl.v3d.CSG.setManipulator().

Here is the call graph for this function:

◆ rot() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.rot	(	Number	x,
		Number	y,
		Number	z
	)

Definition at line 535 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.roty(), and eu.mihosoft.vrl.v3d.CSG.rotz().

Here is the call graph for this function:

◆ rot() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.rot ( Number[] posVector )

Definition at line 539 of file CSG.java.

◆ rotx()

CSG eu.mihosoft.vrl.v3d.CSG.rotx ( Number degreesToRotate )

Rotx.

Parameters

degreesToRotate the degrees to rotate

Returns: the csg

Definition at line 570 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.Parabola.cone(), eu.mihosoft.vrl.v3d.CSG.text(), and eu.mihosoft.vrl.v3d.Fillet.toPolygons().

◆ roty()

CSG eu.mihosoft.vrl.v3d.CSG.roty ( Number degreesToRotate )

Roty.

Parameters

degreesToRotate the degrees to rotate

Returns: the csg

Definition at line 560 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.rot(), eu.mihosoft.vrl.v3d.Isosceles.toPolygons(), and eu.mihosoft.vrl.v3d.Wedge.toPolygons().

◆ rotz()

CSG eu.mihosoft.vrl.v3d.CSG.rotz ( Number degreesToRotate )

Rotz.

Parameters

degreesToRotate the degrees to rotate

Returns: the csg

Definition at line 550 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.Fillet.outerFillet(), eu.mihosoft.vrl.v3d.Extrude.revolve(), eu.mihosoft.vrl.v3d.CSG.rot(), eu.mihosoft.vrl.v3d.Isosceles.toPolygons(), and eu.mihosoft.vrl.v3d.Wedge.toPolygons().

◆ scale()

CSG eu.mihosoft.vrl.v3d.CSG.scale ( Number scaleValue )

Scale.

Parameters

scaleValue the scale value

Returns: the csg

Definition at line 611 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.Dodecahedron.toPolygons(), eu.mihosoft.vrl.v3d.Icosahedron.toPolygons(), eu.mihosoft.vrl.v3d.Octahedron.toPolygons(), and eu.mihosoft.vrl.v3d.Tetrahedron.toPolygons().

◆ scalex()

CSG eu.mihosoft.vrl.v3d.CSG.scalex ( Number scaleValue )

Scalex.

Parameters

scaleValue the scale value

Returns: the csg

Definition at line 601 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.textToSize().

◆ scaley()

CSG eu.mihosoft.vrl.v3d.CSG.scaley ( Number scaleValue )

Scaley.

Parameters

scaleValue the scale value

Returns: the csg

Definition at line 591 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.textToSize().

◆ scalez()

CSG eu.mihosoft.vrl.v3d.CSG.scalez ( Number scaleValue )

Scalez.

Parameters

scaleValue the scale value

Returns: the csg

Definition at line 581 of file CSG.java.

◆ setColor()

CSG eu.mihosoft.vrl.v3d.CSG.setColor ( Color color )

Sets the color.

Parameters

color the new color

Definition at line 207 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.svg.SVGLoad.extrudeLayers(), eu.mihosoft.vrl.v3d.CSG.prepForManufacturing(), eu.mihosoft.vrl.v3d.CSG.regenerate(), and eu.mihosoft.vrl.v3d.CSG.setParameterNewValue().

◆ setDatumReferences()

void eu.mihosoft.vrl.v3d.CSG.setDatumReferences ( ArrayList< Transform > datumReferences )

private

Definition at line 2455 of file CSG.java.

◆ setDefaultColor()

static void eu.mihosoft.vrl.v3d.CSG.setDefaultColor ( Color defaultcolor )

static

Definition at line 2363 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.defaultcolor.

◆ setDefaultOptType()

static void eu.mihosoft.vrl.v3d.CSG.setDefaultOptType ( OptType optType )

static

Sets the default opt type.

Parameters

optType the optType to set

Definition at line 1914 of file CSG.java.

◆ setIsWireFrame()

void eu.mihosoft.vrl.v3d.CSG.setIsWireFrame ( boolean b )

Definition at line 2672 of file CSG.java.

◆ setManipulator()

CSG eu.mihosoft.vrl.v3d.CSG.setManipulator ( Affine manipulator )

Sets the manipulator.

Parameters

manipulator the manipulator

Returns: the affine

Definition at line 235 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.regenerate(), and eu.mihosoft.vrl.v3d.CSG.setParameterNewValue().

◆ setManufactuing()

CSG eu.mihosoft.vrl.v3d.CSG.setManufactuing ( PrepForManufacturing manufactuing )

Definition at line 2236 of file CSG.java.

◆ setManufacturing()

CSG eu.mihosoft.vrl.v3d.CSG.setManufacturing ( PrepForManufacturing manufactuing )

Definition at line 2225 of file CSG.java.

◆ setMfg()

CSG eu.mihosoft.vrl.v3d.CSG.setMfg ( PrepForManufacturing manufactuing )

Definition at line 2221 of file CSG.java.

◆ setName()

CSG eu.mihosoft.vrl.v3d.CSG.setName ( String name )

Definition at line 2382 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG._differenceCSGBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._differenceNoOpt(), eu.mihosoft.vrl.v3d.CSG._differencePolygonBoundsOpt(), eu.mihosoft.vrl.v3d.CSG._unionIntersectOpt(), eu.mihosoft.vrl.v3d.CSG._unionNoOpt(), eu.mihosoft.vrl.v3d.CSG._unionPolygonBoundsOpt(), eu.mihosoft.vrl.v3d.svg.SVGLoad.extrudeLayerToCSG(), eu.mihosoft.vrl.v3d.CSG.intersect(), eu.mihosoft.vrl.v3d.CSG.prepForManufacturing(), and eu.mihosoft.vrl.v3d.CSG.transformed().

◆ setNumFacesInOffset()

static void eu.mihosoft.vrl.v3d.CSG.setNumFacesInOffset ( int numFacesInOffset )

static

Definition at line 2439 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.numFacesInOffset.

Referenced by eu.mihosoft.vrl.v3d.Slice.setNumFacesInOffset().

◆ setOptType()

void eu.mihosoft.vrl.v3d.CSG.setOptType ( OptType optType )

Sets the opt type.

Parameters

optType the optType to set

Definition at line 1923 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.clone().

◆ setParameter() [1/3]

CSG eu.mihosoft.vrl.v3d.CSG.setParameter ( Parameter w )

Definition at line 2250 of file CSG.java.

References eu.mihosoft.vrl.v3d.parametrics.CSGDatabase.get(), eu.mihosoft.vrl.v3d.parametrics.Parameter.getName(), and eu.mihosoft.vrl.v3d.parametrics.Parameter.setValue().

Here is the call graph for this function:

◆ setParameter() [2/3]

CSG eu.mihosoft.vrl.v3d.CSG.setParameter	(	Parameter	w,
		IParametric	function
	)

Definition at line 2240 of file CSG.java.

References eu.mihosoft.vrl.v3d.parametrics.CSGDatabase.get(), eu.mihosoft.vrl.v3d.parametrics.Parameter.getName(), and eu.mihosoft.vrl.v3d.parametrics.CSGDatabase.set().

Referenced by eu.mihosoft.vrl.v3d.Primitive.toCSG().

Here is the call graph for this function:

◆ setParameter() [3/3]

CSG eu.mihosoft.vrl.v3d.CSG.setParameter	(	String	key,
		double	defaultValue,
		double	upperBound,
		double	lowerBound,
		IParametric	function
	)

Definition at line 2262 of file CSG.java.

◆ setParameterIfNull()

CSG eu.mihosoft.vrl.v3d.CSG.setParameterIfNull ( String key )

Definition at line 2271 of file CSG.java.

References eu.mihosoft.vrl.v3d.parametrics.CSGDatabase.get(), and eu.mihosoft.vrl.v3d.parametrics.Parameter.setValue().

Here is the call graph for this function:

◆ setParameterNewValue()

CSG eu.mihosoft.vrl.v3d.CSG.setParameterNewValue	(	String	key,
		double	newValue
	)

Definition at line 2289 of file CSG.java.

References eu.mihosoft.vrl.v3d.parametrics.IParametric.change(), eu.mihosoft.vrl.v3d.CSG.setColor(), and eu.mihosoft.vrl.v3d.CSG.setManipulator().

Here is the call graph for this function:

◆ setPolygons()

void eu.mihosoft.vrl.v3d.CSG.setPolygons ( List< Polygon > polygons )

Sets the polygons.

Parameters

polygons the new polygons

Definition at line 1932 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.clone(), eu.mihosoft.vrl.v3d.CSG.fromPolygons(), and eu.mihosoft.vrl.v3d.CSG.hull().

◆ setPrintBedNumber()

void eu.mihosoft.vrl.v3d.CSG.setPrintBedNumber ( int index )

Definition at line 2676 of file CSG.java.

◆ setProgressMoniter()

static void eu.mihosoft.vrl.v3d.CSG.setProgressMoniter ( ICSGProgress progressMoniter )

static

Definition at line 2355 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.progressMoniter.

◆ setRegenerate()

CSG eu.mihosoft.vrl.v3d.CSG.setRegenerate ( IRegenerate function )

Definition at line 2297 of file CSG.java.

◆ setStorage()

void eu.mihosoft.vrl.v3d.CSG.setStorage ( PropertyStorage storage )

Definition at line 2463 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.fromPolygons().

◆ setTemporaryColor()

CSG eu.mihosoft.vrl.v3d.CSG.setTemporaryColor ( Color color )

Sets the Temporary color.

Parameters

color the new Temporary color

Definition at line 221 of file CSG.java.

◆ setUseStackTraces()

static void eu.mihosoft.vrl.v3d.CSG.setUseStackTraces ( boolean useStackTraces )

static

Definition at line 2447 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.useStackTraces.

◆ text() [1/3]

static CSG eu.mihosoft.vrl.v3d.CSG.text	(	String	text,
		double	height
	)

static

Definition at line 2688 of file CSG.java.

◆ text() [2/3]

static CSG eu.mihosoft.vrl.v3d.CSG.text	(	String	text,
		double	height,
		double	fontSize
	)

static

Definition at line 2685 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.text(), and eu.mihosoft.vrl.v3d.CSG.textToSize().

◆ text() [3/3]

static CSG eu.mihosoft.vrl.v3d.CSG.text	(	String	text,
		double	height,
		double	fontSize,
		String	fontType
	)

static

Definition at line 2691 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.dumbUnion(), eu.mihosoft.vrl.v3d.CSG.rotx(), eu.mihosoft.vrl.v3d.CSG.text(), eu.mihosoft.vrl.v3d.TextExtrude.text, and eu.mihosoft.vrl.v3d.CSG.toZMin().

Here is the call graph for this function:

◆ textToSize()

static CSG eu.mihosoft.vrl.v3d.CSG.textToSize	(	String	text,
		double	x,
		double	y,
		double	z
	)

static

Extrude text to a specific bounding box size

Parameters

text	the text to be extruded
x	the total final X
y	the total final Y
z	the total final Z

Returns: The given input text, scaled to the exact sizes provided, with Y=0 line as the bottom line of the text

Definition at line 2714 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getTotalX(), eu.mihosoft.vrl.v3d.CSG.getTotalY(), eu.mihosoft.vrl.v3d.CSG.scalex(), eu.mihosoft.vrl.v3d.CSG.scaley(), eu.mihosoft.vrl.v3d.CSG.text(), and eu.mihosoft.vrl.v3d.CSG.toXMin().

Here is the call graph for this function:

◆ toJavaFXMesh()

MeshContainer eu.mihosoft.vrl.v3d.CSG.toJavaFXMesh ( CadInteractionEvent interact )

To java fx mesh.

Parameters

interact the interact

Returns: the mesh container

Definition at line 1703 of file CSG.java.

◆ toJavaFXMeshSimple()

MeshContainer eu.mihosoft.vrl.v3d.CSG.toJavaFXMeshSimple ( CadInteractionEvent interact )

Returns the CSG as JavaFX triangle mesh.

Parameters

interact the interact

Returns: the CSG as JavaFX triangle mesh

Definition at line 1727 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSGtoJavafx.meshFromPolygon().

Here is the call graph for this function:

◆ toObjString() [1/2]

String eu.mihosoft.vrl.v3d.CSG.toObjString ( )

Returns this csg in OBJ string format.

Returns: this csg in OBJ string format

Definition at line 1654 of file CSG.java.

◆ toObjString() [2/2]

StringBuilder eu.mihosoft.vrl.v3d.CSG.toObjString ( StringBuilder sb )

Returns this csg in OBJ string format.

Parameters

sb	string builder

Returns: the specified string builder

Definition at line 1567 of file CSG.java.

References eu.mihosoft.vrl.v3d.Vertex.toObjString(), and eu.mihosoft.vrl.v3d.Vertex.transform().

Here is the call graph for this function:

◆ toolOffset()

CSG eu.mihosoft.vrl.v3d.CSG.toolOffset ( Number sn )

Definition at line 2064 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.intersect(), and eu.mihosoft.vrl.v3d.Primitive.toCSG().

Here is the call graph for this function:

◆ toStlString() [1/2]

String eu.mihosoft.vrl.v3d.CSG.toStlString ( )

Returns this csg in STL string format.

Returns: this csg in STL string format

Definition at line 1370 of file CSG.java.

◆ toStlString() [2/2]

StringBuilder eu.mihosoft.vrl.v3d.CSG.toStlString ( StringBuilder sb )

Returns this csg in STL string format.

Parameters

sb	string builder

Returns: the specified string builder

Definition at line 1383 of file CSG.java.

References eu.mihosoft.vrl.v3d.Polygon.toStlString().

Here is the call graph for this function:

◆ toString()

String eu.mihosoft.vrl.v3d.CSG.toString ( )

Definition at line 2388 of file CSG.java.

◆ touching()

boolean eu.mihosoft.vrl.v3d.CSG.touching ( CSG incoming )

A test to see if 2 CSG's are touching. The fast-return is a bounding box check If bounding boxes overlap, then an intersection is performed and the existance of an interscting object is returned

Parameters

incoming

Returns

Definition at line 2335 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getMaxX(), eu.mihosoft.vrl.v3d.CSG.getMaxY(), eu.mihosoft.vrl.v3d.CSG.getMaxZ(), eu.mihosoft.vrl.v3d.CSG.getMinX(), eu.mihosoft.vrl.v3d.CSG.getMinY(), eu.mihosoft.vrl.v3d.CSG.getMinZ(), and eu.mihosoft.vrl.v3d.CSG.getPolygons().

Here is the call graph for this function:

◆ toXMax() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.toXMax ( )

To x max.

Returns: the csg

Definition at line 384 of file CSG.java.

◆ toXMax() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.toXMax ( CSG target )

To x max.

Parameters

target the target

Returns: the csg

Definition at line 328 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.Bounds.getMax(), and eu.mihosoft.vrl.v3d.Vector3d.x().

Referenced by eu.mihosoft.vrl.v3d.CSG.getBoundingBox().

Here is the call graph for this function:

◆ toXMin() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.toXMin ( )

To x min.

Returns: the csg

Definition at line 375 of file CSG.java.

◆ toXMin() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.toXMin ( CSG target )

To x min.

Parameters

target the target

Returns: the csg

Definition at line 318 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.Bounds.getMin(), and eu.mihosoft.vrl.v3d.Vector3d.x().

Referenced by eu.mihosoft.vrl.v3d.CSG.textToSize(), and eu.mihosoft.vrl.v3d.Fillet.toPolygons().

Here is the call graph for this function:

◆ toYMax() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.toYMax ( )

To y max.

Returns: the csg

Definition at line 402 of file CSG.java.

◆ toYMax() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.toYMax ( CSG target )

To y max.

Parameters

target the target

Returns: the csg

Definition at line 348 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.Bounds.getMax(), and eu.mihosoft.vrl.v3d.Vector3d.y().

Referenced by eu.mihosoft.vrl.v3d.CSG.getBoundingBox().

Here is the call graph for this function:

◆ toYMin() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.toYMin ( )

To y min.

Returns: the csg

Definition at line 393 of file CSG.java.

◆ toYMin() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.toYMin ( CSG target )

To y min.

Parameters

target the target

Returns: the csg

Definition at line 338 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.Bounds.getMin(), and eu.mihosoft.vrl.v3d.Vector3d.y().

Referenced by eu.mihosoft.vrl.v3d.Fillet.toPolygons().

Here is the call graph for this function:

◆ toZMax() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.toZMax ( )

To z max.

Returns: the csg

Definition at line 366 of file CSG.java.

◆ toZMax() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.toZMax ( CSG target )

To z max.

Parameters

target the target

Returns: the csg

Definition at line 308 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.Bounds.getMax(), and eu.mihosoft.vrl.v3d.Vector3d.z().

Referenced by eu.mihosoft.vrl.v3d.svg.SVGLoad.extrudeLayers(), and eu.mihosoft.vrl.v3d.CSG.getBoundingBox().

Here is the call graph for this function:

◆ toZMin() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.toZMin ( )

To z min.

Returns: the csg

Definition at line 357 of file CSG.java.

◆ toZMin() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.toZMin ( CSG target )

To z min.

Parameters

target the target

Returns: the csg

Definition at line 298 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.getBounds(), eu.mihosoft.vrl.v3d.Bounds.getMin(), and eu.mihosoft.vrl.v3d.Vector3d.z().

Referenced by eu.mihosoft.vrl.v3d.Parabola.cone(), eu.mihosoft.vrl.v3d.CSG.text(), eu.mihosoft.vrl.v3d.Fillet.toPolygons(), and eu.mihosoft.vrl.v3d.RoundedCylinder.toPolygons().

Here is the call graph for this function:

◆ transformed()

CSG eu.mihosoft.vrl.v3d.CSG.transformed ( Transform transform )

Returns a transformed copy of this CSG.

Parameters

transform the transform to apply

Returns: a transformed copy of this CSG

Definition at line 1676 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.fromPolygons(), eu.mihosoft.vrl.v3d.CSG.historySync(), eu.mihosoft.vrl.v3d.CSG.optimization(), and eu.mihosoft.vrl.v3d.CSG.setName().

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.makeKeepaway(), eu.mihosoft.vrl.v3d.Extrude.revolve(), and eu.mihosoft.vrl.v3d.RoundedCube.toPolygons().

Here is the call graph for this function:

◆ triangulate() [1/2]

CSG eu.mihosoft.vrl.v3d.CSG.triangulate ( )

Definition at line 1398 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.ext.quickhull3d.HullUtil.hull().

◆ triangulate() [2/2]

CSG eu.mihosoft.vrl.v3d.CSG.triangulate ( boolean fix )

Definition at line 1401 of file CSG.java.

References eu.mihosoft.vrl.v3d.Debug3dProvider.clearScreen(), and eu.mihosoft.vrl.v3d.Debug3dProvider.setProvider().

Here is the call graph for this function:

◆ union() [1/3]

CSG eu.mihosoft.vrl.v3d.CSG.union ( CSG csg )

Return a new CSG solid representing the union of this csg and the specified csg.

Note: Neither this csg nor the specified csg are weighted.

   A.union(B)

   +-------+            +-------+
   |       |            |       |
   |   A   |            |       |
   |    +--+----+   =   |       +----+
   +----+--+    |       +----+       |
        |   B   |            |       |
        |       |            |       |
        +-------+            +-------+

Parameters

csg other csg

Returns: union of this csg and the specified csg

Definition at line 736 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.historySync().

Referenced by eu.mihosoft.vrl.v3d.CSG.addTabs(), eu.mihosoft.vrl.v3d.CSG.difference(), eu.mihosoft.vrl.v3d.CSG.intersect(), eu.mihosoft.vrl.v3d.Fillet.outerFillet(), eu.mihosoft.vrl.v3d.ChamferedCube.toPolygons(), eu.mihosoft.vrl.v3d.ChamferedCylinder.toPolygons(), eu.mihosoft.vrl.v3d.RoundedCube.toPolygons(), eu.mihosoft.vrl.v3d.CSG.union(), and eu.mihosoft.vrl.v3d.CSG.unionAll().

Here is the call graph for this function:

◆ union() [2/3]

CSG eu.mihosoft.vrl.v3d.CSG.union ( CSG... csgs )

Return a new CSG solid representing the union of this csg and the specified csgs.

Note: Neither this csg nor the specified csg are weighted.

   A.union(B)

   +-------+            +-------+
   |       |            |       |
   |   A   |            |       |
   |    +--+----+   =   |       +----+
   +----+--+    |       +----+       |
        |   B   |            |       |
        |       |            |       |
        +-------+            +-------+

Parameters

csgs	other csgs

Returns: union of this csg and the specified csgs

Definition at line 857 of file CSG.java.

◆ union() [3/3]

CSG eu.mihosoft.vrl.v3d.CSG.union ( List< CSG > csgs )

Return a new CSG solid representing the union of this csg and the specified csgs.

Note: Neither this csg nor the specified csg are weighted.

   A.union(B)

   +-------+            +-------+
   |       |            |       |
   |   A   |            |       |
   |    +--+----+   =   |       +----+
   +----+--+    |       +----+       |
        |   B   |            |       |
        |       |            |       |
        +-------+            +-------+

Parameters

csgs	other csgs

Returns: union of this csg and the specified csgs

Definition at line 797 of file CSG.java.

References eu.mihosoft.vrl.v3d.ICSGProgress.progressUpdate(), and eu.mihosoft.vrl.v3d.CSG.union().

Here is the call graph for this function:

◆ unionAll() [1/2]

static CSG eu.mihosoft.vrl.v3d.CSG.unionAll ( CSG... csgs )

static

Definition at line 871 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.Fillet.corner(), eu.mihosoft.vrl.v3d.svg.SVGLoad.extrudeLayerToCSG(), and eu.mihosoft.vrl.v3d.Fillet.outerFillet().

◆ unionAll() [2/2]

static CSG eu.mihosoft.vrl.v3d.CSG.unionAll ( List< CSG > csgs )

static

Definition at line 875 of file CSG.java.

References eu.mihosoft.vrl.v3d.CSG.union().

Here is the call graph for this function:

◆ updatePolygons()

void eu.mihosoft.vrl.v3d.CSG.updatePolygons	(	ArrayList< Polygon >	toAdd,
		ArrayList< Polygon >	degenerates,
		Polygon	p
	)

private

Definition at line 1510 of file CSG.java.

References eu.mihosoft.vrl.v3d.Debug3dProvider.addObject(), eu.mihosoft.vrl.v3d.Debug3dProvider.clearScreen(), eu.mihosoft.vrl.v3d.ext.org.poly2tri.PolygonUtil.concaveToConvex(), eu.mihosoft.vrl.v3d.Debug3dProvider.setProvider(), and eu.mihosoft.vrl.v3d.Polygon.vertices.

Here is the call graph for this function:

◆ weighted()

CSG eu.mihosoft.vrl.v3d.CSG.weighted ( WeightFunction f )

Weighted.

Parameters

f the f

Returns: the csg

Definition at line 1665 of file CSG.java.

Member Data Documentation

◆ assembly

PropertyStorage eu.mihosoft.vrl.v3d.CSG.assembly

private

Definition at line 124 of file CSG.java.

◆ bounds

Bounds eu.mihosoft.vrl.v3d.CSG.bounds

private

Definition at line 136 of file CSG.java.

◆ color

Color eu.mihosoft.vrl.v3d.CSG.color = getDefaultColor()

private

The color.

Definition at line 132 of file CSG.java.

◆ current

MeshView eu.mihosoft.vrl.v3d.CSG.current

private

The current.

Definition at line 127 of file CSG.java.

◆ datumReferences

ArrayList<Transform> eu.mihosoft.vrl.v3d.CSG.datumReferences = null

private

Definition at line 148 of file CSG.java.

◆ defaultcolor

Color eu.mihosoft.vrl.v3d.CSG.defaultcolor = Color.web("#007956")

staticprivate

Definition at line 129 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.setDefaultColor().

◆ defaultOptType

OptType eu.mihosoft.vrl.v3d.CSG.defaultOptType = OptType.CSG_BOUND

staticprivate

The default opt type.

Definition at line 117 of file CSG.java.

◆ exportFormats

ArrayList<String> eu.mihosoft.vrl.v3d.CSG.exportFormats = null

private

Definition at line 147 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.prepForManufacturing().

◆ groovyFileLines

ArrayList<String> eu.mihosoft.vrl.v3d.CSG.groovyFileLines = new ArrayList<>()

private

Definition at line 140 of file CSG.java.

◆ INDEX_OF_PARAMETRIC_DEFAULT

final int eu.mihosoft.vrl.v3d.CSG.INDEX_OF_PARAMETRIC_DEFAULT = 0

static

Definition at line 137 of file CSG.java.

◆ INDEX_OF_PARAMETRIC_LOWER

final int eu.mihosoft.vrl.v3d.CSG.INDEX_OF_PARAMETRIC_LOWER = 1

static

Definition at line 138 of file CSG.java.

◆ INDEX_OF_PARAMETRIC_UPPER

final int eu.mihosoft.vrl.v3d.CSG.INDEX_OF_PARAMETRIC_UPPER = 2

static

Definition at line 139 of file CSG.java.

◆ manipulator

Affine eu.mihosoft.vrl.v3d.CSG.manipulator

private

The manipulator.

Definition at line 135 of file CSG.java.

◆ manufactuing

PrepForManufacturing eu.mihosoft.vrl.v3d.CSG.manufactuing = null

private

Definition at line 141 of file CSG.java.

◆ mapOfparametrics

HashMap<String, IParametric> eu.mihosoft.vrl.v3d.CSG.mapOfparametrics = null

private

Definition at line 142 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.prepForManufacturing().

◆ markForRegeneration

boolean eu.mihosoft.vrl.v3d.CSG.markForRegeneration = false

private

Definition at line 144 of file CSG.java.

◆ name

String eu.mihosoft.vrl.v3d.CSG.name = ""

private

Definition at line 145 of file CSG.java.

◆ needsDegeneratesPruned

boolean eu.mihosoft.vrl.v3d.CSG.needsDegeneratesPruned =false

staticprivate

Definition at line 150 of file CSG.java.

◆ numFacesInOffset

int eu.mihosoft.vrl.v3d.CSG.numFacesInOffset = 15

staticprivate

Definition at line 111 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.setNumFacesInOffset().

◆ optType

OptType eu.mihosoft.vrl.v3d.CSG.optType = null

private

The opt type.

Definition at line 120 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.hull().

◆ polygons

List<Polygon> eu.mihosoft.vrl.v3d.CSG.polygons

private

The polygons.

Definition at line 114 of file CSG.java.

◆ progressMoniter

ICSGProgress eu.mihosoft.vrl.v3d.CSG.progressMoniter

staticprivate

Initial value:

= new ICSGProgress() {
        @Override
        public void progressUpdate(int currentIndex, int finalIndex, String type, CSG intermediateShape) {
            System.out.println(type + "ing " + currentIndex + " of " + finalIndex);
        }
    }

Definition at line 153 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.setProgressMoniter().

◆ providerOf3d

IDebug3dProvider eu.mihosoft.vrl.v3d.CSG.providerOf3d = null

staticprivate

Definition at line 110 of file CSG.java.

◆ regenerate

IRegenerate eu.mihosoft.vrl.v3d.CSG.regenerate = null

private

Definition at line 143 of file CSG.java.

◆ slicePlanes

ArrayList<Transform> eu.mihosoft.vrl.v3d.CSG.slicePlanes = null

private

Definition at line 146 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.prepForManufacturing().

◆ str

PropertyStorage eu.mihosoft.vrl.v3d.CSG.str

private

The storage.

Definition at line 123 of file CSG.java.

◆ triangulated

boolean eu.mihosoft.vrl.v3d.CSG.triangulated

private

Definition at line 149 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.dumbUnion().

◆ useStackTraces

boolean eu.mihosoft.vrl.v3d.CSG.useStackTraces = true

staticprivate

Definition at line 151 of file CSG.java.

Referenced by eu.mihosoft.vrl.v3d.CSG.setUseStackTraces().

The documentation for this class was generated from the following file:

src/main/java/eu/mihosoft/vrl/v3d/CSG.java

Classes

Public Member Functions

Static Public Member Functions

Static Public Attributes

Private Member Functions

Private Attributes

Static Private Attributes

Detailed Description

Constructor & Destructor Documentation

◆ CSG()

Member Function Documentation

◆ _differenceCSGBoundsOpt()

◆ _differenceNoOpt()

◆ _differencePolygonBoundsOpt()

◆ _unionCSGBoundsOpt()

◆ _unionIntersectOpt()

◆ _unionNoOpt()

◆ _unionPolygonBoundsOpt()

◆ addCreationEventStackTraceList()

◆ addCreationEventString()

◆ addCreationEventStringList()

◆ addDatumReference()

◆ addExportFormat()

◆ addSlicePlane()

◆ addStackTrace()

◆ addTabs() [1/2]

◆ addTabs() [2/2]

◆ addTabsReorientation()

◆ clearExportFormats()

◆ clone()

◆ color()

◆ difference() [1/3]

◆ difference() [2/3]

◆ difference() [3/3]

◆ dumbUnion()

◆ fixDegenerates()

◆ fromPolygons() [1/4]

◆ fromPolygons() [2/4]

◆ fromPolygons() [3/4]

◆ fromPolygons() [4/4]

◆ getAssemblyStorage()

◆ getBoundingBox()

◆ getBounds()

◆ getCenter()

◆ getCenterX()

◆ getCenterY()

◆ getCenterZ()

◆ getColor()

◆ getCreationEventStackTraceList()

◆ getDatumReferences()

◆ getDefaultColor()

◆ getExportFormats()

◆ getManipulator()

◆ getManufactuing()

◆ getManufacturing()

◆ getMapOfparametrics()

◆ getMaxX()

◆ getMaxY()

◆ getMaxZ()

◆ getMesh()

◆ getMfg()

◆ getMinX()

◆ getMinY()

◆ getMinZ()

◆ getName()

◆ getNumFacesForOffsets()

◆ getNumfacesinoffset()

◆ getNumFacesInOffset()

◆ getOptType()

◆ getParameters()

◆ getPolygons()

◆ getPrintBedIndex()

◆ getProgressMoniter()

◆ getSlicePlanes()

◆ getStorage()

◆ getTotalX()

◆ getTotalY()

◆ getTotalZ()

◆ historySync()

◆ hull() [1/3]
